sony
FS7
€130.00 + iva
Videocamera – Cinecamera – Cinécaméra – Cámara de cine
Progettato come una telecamera adatta a produzioni diverse, come documentari in stile “Cinéma Vérité”, reality TV, applicazioni commerciali e aziendali, il sistema di telecamere PXW-FS7 XDCAM Super 35 di Sony è un sistema di telecamere 4K flessibile. È dotato di un sensore di dimensioni Super 35 mm che consente di catturare immagini con profondità di campo cinematografica. L’attacco E della fotocamera è realizzato in acciaio inossidabile e consente di utilizzare obiettivi con attacco E o con l’uso di adattatori opzionali per accettare la maggior parte degli obiettivi da 35 mm tra cui PL, EF, Leica e Nikon. La fotocamera può acquisire filmati su schede multimediali XQD integrate opzionali in DCI (4096 x 2160), UHD (3840 x 2160) fino a 60 FPS o HD fino a 180 FPS.
SPECIFICHE TECNICHE
CONTENUTO DEL PACCHETTO
| Image Device | Super 35mm Single-Chip Exmor CMOS |
| Lens Mount | Sony E |
| Effective Picture Elements | 17:9 4096 (H) x 2160 (V) |
| 16:9 3840 (H) x 2160 (V) | |
| Signal-to-Noise Ratio | 57 dB (Y) |
| Sensitivity | 2000 lx, 89.9% reflectance |
| T14 (3840 x 2160/23.98p mode 3200K) | |
| ISO Sensitivity | |
| ISO 2000 (S-Log3 Gamma D55 Light source) | |
| Minimum Illumination | 0.7 lux: +18dB,23.98P,Shutter OFF,ND Clear, F1.4 |
| Signal System | NTSC / PAL |
| Built-in Filters | Clear, 1/4, 1/16, 1/64 |
| Built-In ND Filter | Mechanical Filter Wheel with 2 Stop (1/4), 4 Stop (1/16), 6 Stop (1/64) ND Filters |
| LCD Monitor | 3.5″ / 8.8 cm |
| Approx: 1.56M dots | |
| Speaker | Monaural |
| Shutter Speed | 1/3 to 1/9000 of a sec |
| White Balance | Preset |
| Memory A | |
| Memory B (1500K-50000K)/ATW | |
| Gain Selection | -3, 0, 3, 6, 9, 12, 18 dB, AGC |
| Gamma Curve | STD |
| HG | |
| User | |
| S-log3 | |
| Gain | -3 to 18 dB |
| Shooting Formats | 4K 4096 x 2160 |
| 12-bit RAW | |
| UHD 3840 x 2160 | |
| 10-bit 4:2:2 XAVC-I | |
| 8-bit 4:2:0 XAVC-L | |
| 2K 2048 x 1080 | |
| 12-bit Raw | |
| HD 1920 x 1080 | |
| 10-bit 4:2:2 XAVC-I | |
| 10-bit 4:2:2 XAVC-L | |
| MPEG2 4:2:2 | |
| HD 1280 x 720 | |
| MPEG2 4:2:2 | |
| Audio Recording Format | LPCM 24 bits, 48 kHz, 4 channels (Recording/Playback 2 channels) |
| Recording Formats | XAVC-I QFHD MPEG-4 H.264/AVC |
| 59.94P CBG, bit rate 600 Mb/s | |
| 50P CBG, bit rate 500 Mb/s | |
| 29.97P CBG, bit rate 300 Mb/s | |
| 23.98P CBG, bit rate 240 Mb/s | |
| 25P CBG, bit rate 250 Mb/s | |
| XAVC-I HD MPEG-4 H.264/AVC | |
| 59.94P VBR, maximum bit rate 222 Mb/s | |
| 50P VBR, maximum bit rate 185 Mb/s | |
| 59.94i VBR, maximum bit rate 111 Mb/s | |
| 50i VBR, maximum bit rate 112 Mb/s | |
| 29.97p VBR, maximum bit rate 111 Mb/s | |
| 23.98p VBR, maximum bit rate 89 Mb/s | |
| 25p VBR, maximum bit rate 112 Mb/s | |
| XAVC-L QFHD MPEG-4 H.264/AVC | |
| 59.94p/50p mode: VBR, maximum bit rate 150 Mb/s | |
| 29.97p/23.98p/25p mode: VBR, maximum bit rate 100 Mb/s | |
| XAVC-L HD 50 MPEG-4 H.264/AVC | |
| VBR, maximum bit rate 50 Mb/s | |
| XAVC-L HD 35 MPEG-4 H.264/AVC | |
| VBR, maximum bit rate 35 Mb/s | |
| XAVC-L HD 25 MPEG-4 H.264/AVC | |
| VBR, maximum bit rate 25 Mb/s | |
| MPEG-2 Long GOP | |
| CBR, maximum bit rate 50 Mbps, MPEG-2 422P@HL | |
| XAVC-I QFHD 3840 x 2160/ 59.94p, 50p, 29.97p, 23.98p, 25p | |
| XAVC-I HD | |
| 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p | |
| XAVC-L QFHD 50 | |
| 3840 x 2160/59.94p, 50p, 29.97p, 23.98p, 25p | |
| XAVC-L 35 | |
| 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p | |
| MPEG-2 Long GOP | |
| 1920 x 1080/59.94i, 50i, 29.97p, 23.98p, 25p 1280 x 720/59.94p, 50p, 29.97p, 23.98p, 25p | |
| Recording Frame Rate | XAVC-I QFHD |
| 3840 x 2160/ 59.94p, 50p, 29.97p, 23.98p, 25p | |
| XAVC-I HD | |
| 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p | |
| XAVC-L QFHD | |
| 3840 x 2160/59.94p, 50p, 29.97p, 23.98p, 25p | |
| XAVC-L HD 50 | |
| 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p | |
| XAVC-L 35 | |
| 1920 x 1080/59.94p, 50p, 59.94i, 50i, 29.97p, 23.98p, 25p | |
| XAVC-L 25 | |
| 1920 x 1080/59.94i, 50i | |
| MPEG-2 Long GOP MPEG HD422 | |
| 1920 x 1080/59.94i, 50i, 29.97p, 23.98p, 25p | |
| 1280 x 720/59.94p, 50p, 29.97p, 23.98p, 25p | |
| Slow & Quick Motion Function | XAVC-I mode 3840 x 2160: 1 to 60 frames (59.94p, 50p, 29.97p, 23.98p, 25p) |
| XAVC-I mode 1920 x 1080: 1 to 180 frames (59.94p, 29.97p, 23.98p) | |
| XAVC-I mode 1920 x 1080: 1 to 150 frames (50p, 25p) | |
| XAVC-L mode 3840 x 2160: 1 to 60 frames (59.94p, 50p, 29.97p, 23.98p, 25p) | |
| XAVC-L mode 1920 x 1080: 1 to 120 frames (59.94p, 50p, 29.97p, 23.98p, 25p) | |
| Signal-to-Noise Ratio | 57 dB |
| Maximum Recording Time | XAVC-I mode QFHD 59.94p |
| When using QD-G128A (128 GB): Approx. 22 minutes | |
| When using QD-G64A (64 GB) Approx. 11 minutes | |
| XAVC-I mode QFHD 50p | |
| When using QD-G128A (128 GB): Approx. 26 minutes | |
| When using QD-G64A (64 GB) Approx. 13 minutes | |
| XAVC-I mode QFHD 29.97p | |
| When using QD-G128A (128 GB): Approx. 44 minutes | |
| When using QD-G64A (64 GB) Approx. 22 minutes | |
| XAVC-I mode QFHD 23.98p | |
| When using QD-G128A (128 GB): Approx. 55 minutes | |
| When using QD-G64A (64 GB) Approx. 27 minutes | |
| XAVC-I mode QFHD 25p | |
| When using QD-G128A (128 GB): Approx. 52 minutes | |
| When using QD-G64A (64 GB) Approx. 26 minutes | |
| XAVC-I mode HD 59.94p | |
| When using QD-G128A (128 GB): Approx. 59 minutes | |
| When using QD-G64A (64 GB) Approx. 30 minutes | |
| XAVC-I mode HD 50p | |
| When using QD-G128A (128 GB): Approx. 71 minutes | |
| When using QD-G64A (64 GB) Approx. 35 minutes | |
| XAVC-I mode HD 59.94i | |
| When using QD-G128A (128 GB): Approx. 118 minutes | |
| When using QD-G64A (64 GB) Approx. 59 minutes | |
| XAVC-I mode HD 50i | |
| When using QD-G128A (128 GB): Approx. 141 minutes | |
| When using QD-G64A (64 GB) Approx. 70 minutes | |
| XAVC-I mode HD 29.97p | |
| When using QD-G128A (128 GB): Approx. 118 minutes | |
| When using QD-G64A (64 GB) Approx. 59 minutes | |
| XAVC-I mode HD 23.98pM/b> | |
| When using QD-G128A (128 GB): Approx. 147 minutes | |
| When using QD-G64A (64 GB) Approx. 74 minutes | |
| XAVC-I mode HD 25p | |
| When using QD-G128A (128 GB): Approx. 141 minutes | |
| When using QD-G64A (64 GB) Approx. 70 minutes | |
| XAVC-L mode QFHD 59.94p/50p | |
| When using QD-G128A (128 GB): Approx. 87 minutes | |
| When using QD-G64A (64 GB) Approx. 44 minutes | |
| XAVC-L mode QFHD 29.97p/23.98p/25p | |
| When using QD-G128A (128 GB): Approx. 131 minutes | |
| When using QD-G64A (64 GB) Approx. 66 minutes | |
| XAVC-L 50 mode | |
| When using QD-G128A (128 GB): Approx. 262 minutes | |
| When using QD-G64A (64 GB) Approx. 131 minutes | |
| XAVC-L 35 mode | |
| When using QD-G128A (128 GB): Approx. 374 minutes | |
| When using QD-G64A (64 GB) Approx. 187 minutes | |
| XAVC-L 25 mode | |
| When using QD-G128A (128 GB): Approx. 524 minutes | |
| When using QD-G64A (64 GB) Approx. 262 minutes | |
| MPEG HD422 mode | |
| When using QD-G128A (128 GB): Approx. 262 minutes | |
| When using QD-G64A (64 GB) Approx. 131 minutes | |
| Media Card Slots | 2 x XQD |
| 1 x SD (for configuration data only) | |
| Input and Output Connectors | Audio Input |
| 2 x 3-pin XLR | |
| Line/mic/mic +48 | |
| Mic Reference: -40. -50. -60 dBu | |
| SDI Output | |
| 2 x BNC HD/3G-SDI | |
| SMTPE292M/424M/425M | |
| HDMI 2.0 | |
| 1 x Type A | |
| USB | |
| USB device, miniB | |
| Headphone | |
| 1 x Stereo mini jack | |
| -16 dBu 16 Ω | |
| Remote | |
| Stereo mini jack (Φ2.5 mm) | |
| Accessory Shoe | Multi-Interface (MI) shoe |
| Power Requirement | 12 VDC |
| Power Consumption | Approx. 19 W (while recording XAVC-I QFHD 59.94p, SELP28135G Lens, Viewfinder ON, not using external device) |
| Battery Operating Time | BP-U30: Approx. 1 hr while recording XAVC-I QFHD 59.94p, SELP28135G Lens, Viewfinder ON, not using external device |
| BP-U60: Approx. 2 hr while recording XAVC-I QFHD 59.94p, SELP28135G Lens, Viewfinder ON, not using external device | |
| BP-U90: Approx. 3 hr while recording XAVC-I QFHD 59.94p, SELP28135G Lens, Viewfinder ON, not using external device | |
| Temperature | Operating: 32 to 104°F / 0 to 40°C |
| Storage: -4 to 140°F / -4 to 140°C | |
| Dimensions | 6.14 x 9.41 x 9.72″ / 156 x 239 x 247 mm |
| Weight | 4.4 lb / 2.0 kg: Body Only |
| 9.9 lb / 4.4 kg: Body, Viewfinder, Eyepiece, Grip Remote Control, BP-U30 Battery, SELP28135G Lens, an XQD Memory card | |
| Gamma Curve | Sony S-Log 3 |
| Audio Recording | 4-Channel 24-Bit 48 kHz |
| Video I/O | 2 x BNC (3G-SDI) Output |
| 1 x HDMI 2.0 Output | |
| Audio I/O | 2 x 3-Pin XLR Mic/Line (+48 V Phantom Power) Input |
| 1 x 1/8″ / 3.5 mm TRS Stereo Headphone Output | |
| Power I/O | 1 x Barrel Input |
| Other I/O | 1 x Mini-USB Data Input/Output |
| 1 x 2.5 mm Sub-Mini (LANC) Control Input | |
| Environmental | |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Battery Type | Sony BP-U Series |
| Power Consumption | 19 W |
| Accessory Mount | 1 x Intelligent Hot Shoe |
| 1 x 1/4″-20 Female |
- PXW-FS7
- Monitor 3.5″
- Cage con spallaccio Tilta
- Dovetail Tilta
- Coppia di canne da 15 lunghe 30cm
- 3x Batteria BP-U
- Microfono mezzo fucile XLR
- Viewfinder
- Grip Remote Control
- Caricabatterie
- Card reader
- 2x XQD da 64GB
- XQD da 120GB
- Cavo d’alimentazione
- Cavo d-tap
- Valigia di trasporto
Adattatore: +0€+iva
Adattatore Commlite E-Mount-EF
Speedbooster Metabones 0.71x E-Mount-EF
